AEMC AC DC Current Probe Model MR6292 aemc

1 / 2

General Laboratorium Supplies

AEMC AC DC Current Probe Model MR6292 aemc

Price

Rp 1.110 / Unit

*Price includes VAT.

1 Unit Minimum Order

Price is not binding and may change at any time. Get the best price by clicking Request Quotation

Stock: 0
Country of Origin: Australia
Shipped From: Bekasi Utara, Bekasi
Category: General Laboratorium Supplies
Last Updated: 20 Oct 2026

Specifications of AEMC AC DC Current Probe Model MR6292 aemc

Explore a wide selection of General Laboratorium Supplies.

AEMC AC DC Current Probe Model MR6292 aemc

SPESIFIKASI AC/DC CURRENT PROBE MODEL MR6292

Merek: AEMC Instruments

Model: MR6292

Nomor Katalog: 2129.86

Jenis Pengukuran: Arus DC

Teknologi Sensor: Hall Effect

Rentang Pengukuran: 1–50 A DC

Arus Maksimum: 50 A DC

Akurasi: ±(1,5% pembacaan + 0,2 A)

Sinyal Keluaran: 10 mV/A

Impedansi Beban: >100 kΩ / 100 pF

Tegangan Kerja: 600 V RMS

Bukaan Rahang: 31 mm

Diameter Kabel Maksimum: 1 kabel Ø30 mm atau 2 kabel Ø24 mm

Panjang Kabel: 1,5 m

Konektor Keluaran: 5-pin XLR

Catu Daya: Dari AEMC Micro-Ohmmeter Model 6292

Dimensi (P × L × T): 224 × 97 × 44 mm

Berat: ±440 g

Suhu Operasi: −10 hingga +55 °C

Tingkat Proteksi: IP30

Kategori Keselamatan: 600 V CAT III

Fungsi: Pengukuran arus DC untuk pengujian resistansi rendah menggunakan Micro-Ohmmeter AEMC Model 6292, termasuk pengukuran mode BSG (Both Sides Grounded).

Catatan:

Probe MR6292 dirancang khusus untuk digunakan dengan AEMC Micro-Ohmmeter Model 6292 dan tidak ditujukan untuk penggunaan universal dengan multimeter biasa.

Pastikan koneksi dan batas keselamatan dipenuhi sebelum pengukuran.

AEMC AC DC Current Probe Model MR6292 aemc

AC/DC CURRENT PROBE MODEL MR6292 SPECIFICATIONS

Brand: AEMC Instruments

Model: MR6292

Catalog Number: 2129.86

Measurement Type: DC current

Sensor Technology: Hall Effect

Measurement Range: 1–50 A DC

Maximum Current: 50 A DC

Accuracy: ±(1.5% of reading + 0.2 A)

Output Signal: 10 mV/A

Load Impedance: >100 kΩ / 100 pF

Working Voltage: 600 V RMS

Jaw Opening: 31 mm

Maximum Cable Diameter: One cable Ø30 mm or two cables Ø24 mm

Cable Length: 1.5 m

Output Connector: 5-pin XLR

Power Supply: Powered by AEMC Micro-Ohmmeter Model 6292

Dimensions (L × W × H): 224 × 97 × 44 mm

Weight: Approx. 440 g

Operating Temperature: −10 to +55 °C

Ingress Protection: IP30

Safety Category: 600 V CAT III

Function: Measures DC current for low-resistance testing with the AEMC Model 6292 Micro-Ohmmeter, including Both Sides Grounded (BSG) mode.

Note:

The MR6292 is specifically designed for use with the AEMC Model 6292 Micro-Ohmmeter and is not intended for general use with standard multimeters.

Ensure proper connections and observe all safety limits before measurement.
