SPESIFIKASI AC/DC CURRENT PROBE MODEL MR525 (BAHASA INDONESIA)

Merek: AEMC Instruments

Model: MR525

Nomor Katalog: 1200.81

Model Pengganti: MR520, Cat. No. 1200.71

Jenis Pengukuran: Arus AC dan DC

Teknologi Sensor: Hall Effect

Rentang Arus AC: 0,5–1.000 A

Rentang Arus DC: 0,5–1.400 A

Sensitivitas Keluaran: 1 mV/A

Rentang Frekuensi: DC–30 kHz (−3 dB)

Akurasi: ±2,5% pada 800 A, 50/60 Hz

Pergeseran Fase: Maks. 1,5° pada 800 A, 50 Hz

Impedansi Beban: >1 MΩ dan ≤100 pF

Diameter Konduktor Maksimum: 39 mm untuk satu kabel

Panjang Kabel: 1,5 m

Konektor Keluaran: 2 × safety banana plug 4 mm

Catu Daya: Baterai alkaline 9 V atau adaptor 5 V DC Micro-USB

Masa Pakai Baterai: Sekitar 50 jam

Dimensi (T × L × D): 236,5 × 97 × 44 mm

Berat: Sekitar 520 g termasuk baterai

Suhu Operasi: −10 hingga +55 °C

Kategori Keselamatan: 600 V CAT III

Fungsi: Mengukur arus AC/DC berkapasitas tinggi untuk pengujian dan pemeliharaan sistem kelistrikan.

Catatan:

MR525 merupakan pengganti MR520.

Pastikan alat ukur kompatibel dengan sensitivitas keluaran 1 mV/A dan selalu patuhi batas pengukuran serta kategori keselamatan.

AEMC AC DC Current Probe Model MR525 Replaces Model MR520 aemc

AC/DC CURRENT PROBE MODEL MR525 SPECIFICATIONS

Brand: AEMC Instruments

Model: MR525

Catalog Number: 1200.81

Replacement for: MR520, Cat. No. 1200.71

Measurement Type: AC and DC current

Sensor Technology: Hall Effect

AC Current Range: 0.5–1,000 A

DC Current Range: 0.5–1,400 A

Output Sensitivity: 1 mV/A

Frequency Range: DC–30 kHz (−3 dB)

Accuracy: ±2.5% at 800 A, 50/60 Hz

Phase Shift: Max. 1.5° at 800 A, 50 Hz

Load Impedance: >1 MΩ and ≤100 pF

Maximum Conductor Diameter: 39 mm for a single cable

Cable Length: 1.5 m

Output Connector: 2 × 4 mm safety banana plugs

Power Supply: 9 V alkaline battery or 5 V DC Micro-USB adapter

Battery Life: Approximately 50 hours

Dimensions (H × W × D): 236.5 × 97 × 44 mm

Weight: Approximately 520 g including battery

Operating Temperature: −10 to +55 °C

Safety Category: 600 V CAT III

Function: Measures high-range AC/DC current for electrical system testing and maintenance.

Note:

The MR525 replaces the MR520.

Ensure that the measuring instrument is compatible with the 1 mV/A output sensitivity and always observe the specified measurement limits and safety category.
