SPESIFIKASI AC/DC CURRENT PROBE MODEL MR526 (BAHASA INDONESIA)

Merek: AEMC Instruments

Model: MR526

Nomor Katalog: 1200.83

Model Pengganti: MR521, Cat. No. 1200.69

Jenis Pengukuran: Arus AC dan DC

Teknologi Sensor: Hall Effect

Rentang Arus AC: 0,5–100 A dan 0,5–1.000 A

Rentang Arus DC: 0,5–150 A dan 0,5–1.400 A

Sensitivitas Keluaran: 10 mV/A dan 1 mV/A

Akurasi pada 50/60 Hz: ≤1,5% pada 100 A dan ≤2,5% pada 800 A

Rentang Frekuensi: DC–30 kHz (−3 dB), bergantung pada arus

Pergeseran Fase pada 50 Hz: ≤2° pada 100 A dan ≤1,5° pada 800 A

Impedansi Beban: >1 MΩ dan ≤100 pF

Ukuran Konduktor Maksimum: Kabel tunggal Ø39 mm atau dua kabel Ø25,4 mm

Panjang Kabel: 1,5 m

Konektor Keluaran: 2 × safety banana plug 4 mm

Catu Daya: Baterai alkaline 9 V atau adaptor 5 V DC Micro-USB

Masa Pakai Baterai: Sekitar 50 jam

Pengaturan Nol DC: Otomatis pada kedua rentang

Dimensi (T × L × D): 236 × 97 × 44 mm

Berat: Sekitar 521 g termasuk baterai

Suhu Operasi: −10 hingga +55 °C

Kategori Keselamatan: 600 V CAT III

Fungsi: Mengukur arus AC dan DC berkapasitas tinggi, cocok untuk multimeter digital, data logger, dan power analyzer.

Catatan:

MR526 merupakan pengganti model MR521.

Pastikan pemilihan rentang, koneksi instrumen, dan kategori keselamatan sesuai dengan kebutuhan pengukuran.

AEMC AC DC Current Probe Model MR526 Replaces Model MR 521 aemc

AC/DC CURRENT PROBE MODEL MR526 SPECIFICATIONS (ENGLISH)

Brand: AEMC Instruments

Model: MR526

Catalog Number: 1200.83

Replacement for: MR521, Cat. No. 1200.69

Measurement Type: AC and DC current

Sensor Technology: Hall Effect

AC Current Range: 0.5–100 A and 0.5–1,000 A

DC Current Range: 0.5–150 A and 0.5–1,400 A

Output Sensitivity: 10 mV/A and 1 mV/A

Accuracy at 50/60 Hz: ≤1.5% at 100 A and ≤2.5% at 800 A

Frequency Range: DC–30 kHz (−3 dB), depending on current

Phase Shift at 50 Hz: ≤2° at 100 A and ≤1.5° at 800 A

Load Impedance: >1 MΩ and ≤100 pF

Maximum Conductor Size: One cable Ø39 mm or two cables Ø25.4 mm

Cable Length: 1.5 m

Output Connector: 2 × 4 mm safety banana plugs

Power Supply: 9 V alkaline battery or 5 V DC Micro-USB adapter

Battery Life: Approximately 50 hours

DC Zero Adjustment: Automatic on both ranges

Dimensions (H × W × D): 236 × 97 × 44 mm

Weight: Approximately 521 g including battery

Operating Temperature: −10 to +55 °C

Safety Category: 600 V CAT III

Function: Measures high-range AC and DC current and is suitable for digital multimeters, data loggers, and power analyzers.

Note:

The MR526 replaces the MR521.

Ensure that the selected range, instrument connections, and safety category are appropriate for the intended measurement.
