AC/DC Current Probe Model SL361

Merek: AEMC Instruments

Jenis: Probe arus AC/DC

Teknologi: Sensor Hall Effect

Rentang pengukuran: 100 mA–100 A peak

Sensitivitas keluaran: 100 mV/A dan 10 mV/A

Bandwidth: DC–100 kHz

Catu daya: Baterai 9 V atau USB 5 V

Koneksi keluaran: Kabel koaksial dengan konektor BNC

Diameter konduktor maksimum: 11,8 mm

Fungsi: Mengukur arus AC dan DC tanpa memutus rangkaian.

Catatan: Rentang pengukuran dan akurasi bergantung pada sensitivitas yang digunakan. Pastikan kesesuaian spesifikasi dengan dokumentasi resmi produsen.

AEMC AC DC Current Probe Model SL361 aemc

TECHNICAL SPECIFICATIONS

AC/DC Current Probe Model SL361

Brand: AEMC Instruments

Type: AC/DC current probe

Technology: Hall-effect sensor

Measurement range: 100 mA–100 A peak

Output sensitivity: 100 mV/A and 10 mV/A

Bandwidth: DC–100 kHz

Power supply: 9 V battery or 5 V USB

Output connection: Coaxial cable with BNC connector

Maximum conductor diameter: 11.8 mm

Function: Measures AC and DC current without interrupting the circuit.

Note: Measurement range and accuracy depend on the selected sensitivity. Verify specifications against the manufacturer's official documentation.
