AEMC AC DC Current Probe Model MR417 Replaces Model MR461 aemc

AEMC AC DC Current Probe Model MR417 Replaces Model MR461 aemc

Merek: AEMC Instruments

Model: MR417

Nomor Katalog: 1200.84

Model Pengganti: MR461, Cat. No. 1200.72

Jenis Pengukuran: Arus AC dan DC

Teknologi Sensor: Hall Effect

Rentang Arus AC: 0,5–40 A dan 0,5–400 A

Rentang Arus DC: 0,5–60 A dan 0,5–600 A

Sensitivitas Keluaran: 10 mV/A dan 1 mV/A

Akurasi pada 50/60 Hz: ≤1,5% pada 40 A dan ≤2% pada 400 A

Rentang Frekuensi: DC–30 kHz (−3 dB), bergantung pada nilai arus

Pergeseran Fase pada 50 Hz: ≤2° pada 40 A dan ≤1,5° pada 400 A

Impedansi Beban: >1 MΩ dan ≤100 pF

Ukuran Konduktor Maksimum: Diameter kabel hingga 30 mm; juga mendukung busbar sesuai ukuran yang ditentukan produsen

Panjang Kabel: 2 m

Konektor Keluaran: BNC terisolasi

Catu Daya: Baterai alkaline 9 V atau adaptor 5 V DC Micro-USB

Masa Pakai Baterai: Sekitar 50 jam

Pengaturan Nol DC: Otomatis pada kedua rentang

Indikator Baterai Lemah: LED hijau berkedip

Indikator Kelebihan Rentang: LED merah menyala

Dimensi (T × L × D): 224 × 97 × 44 mm

Berat: Sekitar 440 g termasuk baterai

Suhu Operasi: −10 hingga +55 °C

Tingkat Proteksi: IP40

Kategori Keselamatan: 600 V CAT III

Fungsi: Mengukur arus AC/DC dan menampilkan bentuk gelombang arus melalui osiloskop atau instrumen dengan input BNC yang kompatibel.

AEMC AC DC Current Probe Model MR417 Replaces Model MR461 aemc

Brand: AEMC Instruments

Model: MR417

Catalog Number: 1200.84

Replacement for: MR461, Cat. No. 1200.72

Measurement Type: AC and DC current

Sensor Technology: Hall Effect

AC Current Range: 0.5–40 A and 0.5–400 A

DC Current Range: 0.5–60 A and 0.5–600 A

Output Sensitivity: 10 mV/A and 1 mV/A

Accuracy at 50/60 Hz: ≤1.5% at 40 A and ≤2% at 400 A

Frequency Range: DC–30 kHz (−3 dB), depending on current

Phase Shift at 50 Hz: ≤2° at 40 A and ≤1.5° at 400 A

Load Impedance: >1 MΩ and ≤100 pF

Maximum Conductor Size: Cable diameter up to 30 mm; busbars supported within manufacturer-specified dimensions

Cable Length: 2 m

Output Connector: Insulated BNC

Power Supply: 9 V alkaline battery or 5 V DC Micro-USB adapter

Battery Life: Approximately 50 hours

DC Zero Adjustment: Automatic on both ranges

Low Battery Indicator: Blinking green LED

Overrange Indicator: Red LED illuminates

Dimensions (H × W × D): 224 × 97 × 44 mm

Weight: Approximately 440 g including battery

Operating Temperature: −10 to +55 °C

Ingress Protection: IP40

Safety Category: 600 V CAT III

Function: Measures AC/DC current and displays current waveforms through compatible oscilloscopes or instruments with BNC inputs.
