SPESIFIKASI AC/DC CURRENT PROBE MODEL MR415

Merek: AEMC Instruments

Model: MR415

Nomor Katalog: 1200.80

Model Pengganti: MR410, Cat. No. 1200.70

Jenis Pengukuran: Arus AC dan DC

Teknologi Sensor: Hall Effect

Rentang Arus AC: 0,5–400 A

Rentang Arus DC: 0,5–600 A

Sensitivitas Keluaran: 1 mV/A

Akurasi pada 50/60 Hz: ≤2% pada 400 A

Rentang Frekuensi: DC–30 kHz (−3 dB), bergantung pada arus

Pergeseran Fase pada 50 Hz: ≤1,5° pada 400 A

Impedansi Beban: >1 MΩ dan ≤100 pF

Arus Kelebihan Beban: 3.000 A DC atau 1.000 A AC kontinu pada frekuensi di bawah 1 kHz

Diameter Konduktor Maksimum: Satu kabel Ø30 mm atau dua kabel Ø24 mm

Ukuran Busbar Maksimum: Satu busbar 50 × 10 mm

Panjang Kabel: 1,5 m

Konektor Keluaran: 2 × safety banana plug 4 mm

Catu Daya: Baterai alkaline 9 V atau adaptor 5 V DC Micro-USB

Masa Pakai Baterai: Sekitar 50 jam

Pengaturan Nol DC: Otomatis

Indikator Baterai Lemah: LED hijau berkedip

Indikator Kelebihan Rentang: LED merah menyala

Dimensi (T × L × D): 224 × 97 × 44 mm

Berat: Sekitar 440 g termasuk baterai

Suhu Operasi: −10 hingga +55 °C

Tingkat Proteksi: IP40

Kategori Keselamatan: 600 V CAT III

Fungsi: Mengukur arus AC/DC untuk multimeter digital, data logger, dan power analyzer.

AEMC AC DC Current Probe Model MR415 Replaces Model MR410 aemc

AC/DC CURRENT PROBE MODEL MR415 SPECIFICATIONS

Brand: AEMC Instruments

Model: MR415

Catalog Number: 1200.80

Replacement for: MR410, Cat. No. 1200.70

Measurement Type: AC and DC current

Sensor Technology: Hall Effect

AC Current Range: 0.5–400 A

DC Current Range: 0.5–600 A

Output Sensitivity: 1 mV/A

Accuracy at 50/60 Hz: ≤2% at 400 A

Frequency Range: DC–30 kHz (−3 dB), depending on current

Phase Shift at 50 Hz: ≤1.5° at 400 A

Load Impedance: >1 MΩ and ≤100 pF

Overload Current: 3,000 A DC or 1,000 A AC continuous at frequencies below 1 kHz

Maximum Conductor Diameter: One cable Ø30 mm or two cables Ø24 mm

Maximum Busbar Size: One busbar measuring 50 × 10 mm

Cable Length: 1.5 m

Output Connector: 2 × 4 mm safety banana plugs

Power Supply: 9 V alkaline battery or 5 V DC Micro-USB adapter

Battery Life: Approximately 50 hours

DC Zero Adjustment: Automatic

Low Battery Indicator: Blinking green LED

Overrange Indicator: Red LED illuminates

Dimensions (H × W × D): 224 × 97 × 44 mm

Weight: Approximately 440 g including battery

Operating Temperature: −10 to +55 °C

Ingress Protection: IP40

Safety Category: 600 V CAT III

Function: Measures AC/DC current for digital multimeters, data loggers, and power analyzers.
