Gasket KLINGER® Top-sil ML1 Synthetic Fiber + Elastomer Compound (HNBR/NBR)

Buy KLINGER top-sil ML1 Gasket Sheet Original - Multi-layer HNBR NBR

Flange joint leakage across high-temperature and high-pressure lines reduces plant operational efficiency. Piping connections require multi-layer sealing materials to extend component service life. Open our Beranda page to obtain tested engineering sealing solutions. We supply genuine KLINGER top-sil ML1 Gasket Sheet to preserve your plant operational reliability. This yellow multi-layer HNBR NBR gasket sheet combines synthetic fibers with a combination of HNBR and NBR elastomers in a layered matrix. Review alternative sheet sizes and sealing options inside our official Katalog Produk menu.

Mechanical Advantages and Multi-Layer HNBR NBR Structure

• Multi-Layer Matrix Construction: Combines synthetic fibers with distinct elastomers in a multi-layer structure for enhanced flexibility at elevated temperatures.
• HNBR and NBR Rubber Combination: Blends HNBR and NBR rubber compounds for high chemical resistance and long-term elasticity.
• Extended Component Service Life: Increases gasket operational longevity and reduces flange maintenance intervals.
• Creep and Cold Flow Resistance: Prevents structural deformation under constant bolt stress and thermal cycles.
• Precision Joint Tightness: Ensures tight sealing across standard piping flanges inside our comprehensive Katalog Gasket collection.

Technical Specifications and Operating Boundaries

• Official Designation: KLINGER top-sil ML1 Gasket Sheet.
• Material Composition: Synthetic fibers and elastomer compound (HNBR/NBR) bound in a multi-layer structure.
• Color and Finish Options: Yellow sheet.
• Material Density: Rated at 1.7 g/cm³.
• Compressibility and Recovery (ASTM F 36 J): Averages 9% compressibility with a recovery rating of 50%.
• Stress Relaxation (DIN 52913 & BS 7531): Rated at 34 MPa (50 MPa, 16 h at 175°C), 28 MPa (50 MPa, 16 h at 300°C), and 29 MPa (BS 7531: 40 MPa, 16 h at 300°C).
• KLINGER Cold/Hot Compression (50 MPa): Thickness decrease recorded at 8% at 23°C and 15% at 300°C.
• Tightness Rating (DIN 28090-2 & VDI 2440): Achieves DIN 28090-2 sealability rate of 0.05 mg/s x m and TA-Luft VDI 2440 specific leak rate of 3.51E-06 mbar x l/s x m.
• Fluid Immersion Thickness Increase (ASTM F 146): 4% increase in IRM 903 oil (5 hours at 150°C) and 8% increase in Fuel B (5 hours at 23°C).
• Standard Sheet Dimensions: Sheet size of 2000 x 1500 mm with available thicknesses of 0.8 mm, 1.0 mm, 1.5 mm, 2.0 mm, and 3.0 mm (thickness tolerance acc. to DIN 28091-1, length/width ±50 mm).
• Flange Cutting Standards: Precision gasket cutting requires exact techniques. Access complete joint connection guidelines via our official Artikel Gasket link.

Electrical Properties, Thermal Conductivity, and ASME Design Factors

• Electrical Insulation Properties: Average surface resistance rated at 9.3x10E12 Ω, specific volume resistance 3.8x10E12 Ω cm, dielectric strength 18.8 kV/mm, power factor 0.048 (50 Hz), and dielectric coefficient 7.3 (50 Hz).
• Thermal Conductivity: Features a thermal conductivity rating of 0.36 W/mK.
• BS 7531:2006 Standard Classification: Classified as Grade AX.
• ASME Code Sealing Factors (Tightness Class 0.1 mg/s x m): 1.0 mm thickness features y = 15 MPa, m = 1.5; 2.0 mm thickness features y = 15 MPa, m = 2.2; 3.0 mm thickness features y = 15 MPa, m = 4.0. Review our technical background on the Tentang Perusahaan page.

International Certifications and Industrial Applications

• Official Approvals and Certifications: Fully certified under Oxygen-tested, DIN-DVGW, TA-Luft (Clean air), DNV approval, and Fire-Safe acc. to DIN EN ISO 10497.
• Compatible Fluid Media: Resistant to oils, water, steam, gases, salt solutions, fuels, alcohols, moderate organic and inorganic acids, hydrocarbons, lubricants, and refrigerants.
• Target Industrial Sectors: Broadly deployed across chemical processing, oil and gas, energy, infrastructure, pulp and paper, marine, automotive, and food and beverage sectors. Open our Kontak page to request price quotes and stock availability.
