Gasket KLINGER® Graphite Laminate TSM Impregnated Expanded Graphite Tanged Stainless Steel Insert

KLINGER® Graphite Laminate TSM Impregnated Expanded Graphite Tanged Stainless Steel Insert – TA‑Luft Low Leakage High Temperature Gasket

CV Jaya Utama Packing supplies KLINGER® Graphite Laminate TSM for low‑leakage flange sealing under high temperatures up to 450°C. This gasket consists of impregnated expanded graphite layers mechanically bonded without adhesive to a 0.1 mm thick tanged stainless steel insert (AISI 316 / 1.4401 or 1.4404). The material complies with TA‑Luft (Clean Air) emission standards while retaining physical properties under thermal stress.

• Certificates & Approvals: Compliant with TA‑Luft (Clean Air) regulations and BABAM-tested
• Low‑Emission Sealing: Impregnated graphite formulation minimizes fugitive fluid and gas emissions across flange joints.
• Mechanical Tanged Reinforcement: Tanged metal insert locks mechanically without adhesives to ensure joint integrity at elevated temperatures.
• Official B2B Compliance: Tax Invoice included with corporate orders.

Technical Specifications & Material Parameters (2.0 mm Test)

Chemical Resistance & Media Compatibility

KLINGER® Graphite Laminate TSM gasket material is tested across various industrial media:

• Emission‑Sensitive Gases & Vapors: Reduces fugitive gas leakage to satisfy TA‑Luft environmental requirements.
• Paraffinic & Aromatic Hydrocarbons: Highly resistant to crude oil, motor fuels, and refined fractions.
• Industrial Solvents: Stable when exposed to ketones, alcohols, esters, and mineral lubricants.
• Diluted Acids & Bases: Resists chemical attack from weak acids and bases.

Target Industries & Application Recommendations

Low leakage performance coupled with high-temperature capability makes this gasket material suitable for sensitive applications:

• Equipment Types: Refinery piping flanges, high‑temperature steam headers, chemical reactors, and process flange connections.
• Target Industries: Chemical Processing, Oil Refineries, Power Generation, Oil & Gas, Pulp & Paper, Marine, and Automotive.

Sheet Dimensions & Size Tolerances

About CV Jaya Utama Packing

Gasket service life depends on proper storage and installation procedures. CV Jaya Utama Packing delivers genuine KLINGER® gasket sheets and custom-cut gasket fabrication. Browse other sealing grades in our gasket product catalog. For technical advice regarding flange installation and chemical selection, read our gasket articles section. Contact our sales engineers for official quotations and delivery schedules.
