SPESIFIKASI DIGITAL MULTIMETER MODEL 5233

Merek/Model: AEMC Instruments 5233

Jenis: Multimeter Digital True RMS

Tampilan: LCD dengan lampu latar, 6.000 counts

Tegangan AC/DC: Hingga 1.000 V AC / 600 V DC

Arus AC/DC: Hingga 10 A (15 A maks. 60 detik)

Resistansi: Hingga 60 MΩ

Frekuensi: Hingga 3 kHz

Kapasitansi: Hingga 1 mF

Fungsi tambahan: Suhu, kontinuitas, dioda, duty cycle, dan deteksi tegangan tanpa kontak (NCV)

Catu daya: Baterai alkaline 9 V

Perlindungan: IP54

Dimensi/Berat: 155 × 75 × 55 mm / ±320 g

Kategori keselamatan: CAT III 1000 V / CAT IV 600 V.

Catatan:

Pengukuran suhu menggunakan termokopel tipe K.

Aksesori standar meliputi kabel pengukuran, adaptor termokopel, tas pembawa, dan buku panduan.

AEMC Digital Multimeter Model 5233 aemc

DIGITAL MULTIMETER MODEL 5233 SPECIFICATIONS

Brand/Model: AEMC Instruments 5233

Type: True RMS Digital Multimeter

Display: Backlit LCD, 6,000 counts

AC/DC Voltage: Up to 1,000 V AC / 600 V DC

AC/DC Current: Up to 10 A (15 A for max. 60 seconds)

Resistance: Up to 60 MΩ

Frequency: Up to 3 kHz

Capacitance: Up to 1 mF

Additional Functions: Temperature, continuity, diode, duty cycle, and non-contact voltage detection (NCV)

Power Supply: 9 V alkaline battery

Protection Rating: IP54

Dimensions/Weight: 155 × 75 × 55 mm / approx. 320 g

Safety Category: CAT III 1000 V / CAT IV 600 V.

Note:

Temperature measurement requires a type K thermocouple.

Standard accessories include test leads, a thermocouple adapter, a carrying case, and a user manual.
