SPESIFIKASI DIGITAL MULTIMETER METRIX MTX 3291

Merek/Model: METRIX MTX 3291

Jenis: Multimeter Digital True RMS

Tampilan: LCD monokrom dengan lampu latar, 60.000 counts

Tegangan DC/AC: Hingga 1.000 V

Arus DC/AC: Hingga 10 A (20 A maks. 30 detik)

Resistansi: Hingga 60 MΩ

Frekuensi: 60 Hz–600 kHz

Kapasitansi: Hingga 60 mF

Fungsi: Pengukuran suhu, kontinuitas, dioda, dan duty cycle

Konektivitas: USB optik

Catu daya: 4 baterai AA

Perlindungan: IP67

Dimensi/Berat: 196 × 90 × 47,1 mm / ±570 g

Kategori keselamatan: CAT III 1000 V / CAT IV 600 V.

AEMC Instruments

Catatan:

Pengukuran suhu menggunakan sensor yang sesuai.

Periksa datasheet resmi untuk memastikan rentang, akurasi, dan aksesori yang disertakan.

AEMC Digital Multimeter Model MTX 3291 aemc

DIGITAL MULTIMETER METRIX MTX 3291 SPECIFICATIONS

Brand/Model: METRIX MTX 3291

Type: True RMS Digital Multimeter

Display: Backlit monochrome LCD, 60,000 counts

DC/AC Voltage: Up to 1,000 V

DC/AC Current: Up to 10 A (20 A for max. 30 seconds)

Resistance: Up to 60 MΩ

Frequency: 60 Hz–600 kHz

Capacitance: Up to 60 mF

Functions: Temperature, continuity, diode, and duty cycle measurement

Connectivity: Optical USB

Power Supply: 4 AA batteries

Protection Rating: IP67

Dimensions/Weight: 196 × 90 × 47.1 mm / approx. 570 g

Safety Category: CAT III 1000 V / CAT IV 600 V.

Note:

Temperature measurement requires a compatible sensor.

Refer to the official datasheet to confirm ranges, accuracy, and included accessories.
