Style 5898 Continuous Filament PTFE Fiber Compression Packing
- Country of OriginIndonesia
- Shipped FromTaman Sari, Jakarta Barat
- Category
- Last Updated19 Oct 2026
Specifications of Style 5898 Continuous Filament PTFE Fiber Compression Packing
Explore a wide selection of Non Asbestos Gland Packing.Style 5898 Continuous Filament PTFE Fiber Compression Packing – Oxygen Service Grade
CV Jaya Utama Packing supplies Style 5898 Compression Packing designed for oxygen service applications. Braided from continuous filament PTFE yarns treated with pure PTFE dispersion, this packing contains no organic oils or lubricants, preventing leakage in liquid and gaseous oxygen systems.
- Regulatory Compliance: Fully certified for oxygen service, REACH-compliant, and ADI/TSE Free.
- Official Documentation: Complete Certificate of Analysis (CoA) and Material Safety Data Sheet (MSDS) provided upon request.
- Custom Fabrication: Precision pre-cut gland packing rings engineered to fit your exact stuffing box dimensions.
- Official B2B Compliance: Tax Invoice (PPN) included with corporate orders.
Technical Specifications & Operational Parameters
| Technical Parameter | Operational Limits |
|---|---|
| Base Material / Composition | Continuous Filament PTFE Yarns Impregnated with PTFE Dispersion |
| Additional Lubricants | PTFE Dispersion (No Organic Oils / Organic Lubricant Free) |
| Braid Construction Style | Lattice Braid® |
| Temperature Limits | -270°C to +260°C (-450°F to +500°F) |
| Max Valve Pressure | 138 Bar (2000 PSI) |
| Max Rotary Pressure | 20 Bar (300 PSI) |
| Max Shaft Surface Speed | 5 m/s (1000 fpm) |
| Chemical Resistance (pH Range) | pH 0 – 14 |
| Cross Section Shape | Square Cross-Section |
| Regulatory Compliance | Certified for Oxygen Service, REACH Compliant, ADI/TSE Free |
Key Product Advantages Over Competitors
- Safe for Oxygen Service: Organic oil-free formulation eliminates combustion risks in high-pressure gaseous and liquid oxygen environments.
- Dense & Pre-Shrunk: Pre-conditioned structure ensures dimensional stability and forms a tight, firm seal.
- Universal Chemical Immunity (pH 0-14): Pure PTFE filaments resist aggressive chemicals and process fluids.
- High Cleanliness Standards: Manufactured under controlled conditions to maintain product cleanliness and traceability.
Recommended Applications & Target Industries
Style 5898 Compression Packing is ideal for high-cleanliness equipment:
- Equipment Types: Industrial valves, oxygen piping systems, and high-cleanliness fluid handling equipment.
- Media Compatibility: Gaseous oxygen, liquid oxygen, and pure chemical fluids.
- Target Industries: Oil & Gas, Chemical Processing, Mining, Primary Metals, and Water & Wastewater Processing.
Complete Part Number Variant, Size & Packaging List
| Part Number | Cross Section Size (Inch/mm) | Package Type | Package Weight | Yield Ratio (Ft/Lb / m/kg) |
|---|---|---|---|---|
| 41540-1008 | 0.125" (3.18 mm) | Spool | 1 lb | 80.43 Ft/Lb |
| 41540-1212 | 0.188" (4.78 mm) | Spool | 2 lb | 38.99 Ft/Lb |
| 41540-2012 | 0.188" (4.78 mm) | Spool | 5 lb | 37.13 Ft/Lb |
| 41540-2016 | 0.250" (6.35 mm) | Spool | 5 lb | 22.19 Ft/Lb |
| 41540-2020 | 0.313" (7.95 mm) | Spool | 5 lb | 13.33 Ft/Lb |
| 41540-2024 | 0.375" (9.53 mm) | Spool | 5 lb | 10.52 Ft/Lb |
| 41540-2028 | 0.438" (11.13 mm) | Spool | 5 lb | 7.41 Ft/Lb |
| 41540-1232 | 0.500" (12.70 mm) | Spool | 2 lb | 6.01 Ft/Lb |
| 41540-2032 | 0.500" (12.70 mm) | Spool | 5 lb | 5.73 Ft/Lb |
| 41540-0032 | 0.500" (12.70 mm) | Reel | 50 lb | 6.01 Ft/Lb |
| 41540-3040 | 0.625" (15.88 mm) | Spool | 10 lb | 3.74 Ft/Lb |
| 41540-5040 | 0.625" (15.88 mm) | Reel | 25 lb | 3.93 Ft/Lb |
| 41540-3048 | 0.750" (19.05 mm) | Spool | 10 lb | 2.57 Ft/Lb |
| 41540-5048 | 0.750" (19.05 mm) | Reel | 25 lb | 2.70 Ft/Lb |
| 41540-3050 | 0.787" (19.99 mm) | Spool | 10 lb | 2.38 Ft/Lb (1.07 m/kg) |
