Garlock Style 19 SBR Rubber Sheet

Garlock Style 19 SBR Rubber Sheet

Flange joint leakage in industrial water lines compromises plant operational efficiency. Flange connections require strong structural sealing materials to resist physical deformation under load. We supply genuine Garlock Style 19 SBR Rubber Sheet to maintain your system's operational stability. This premium SBR Rubber Sheet is reinforced with cotton fabric to provide added mechanical strength across piping joints.

Mechanical Advantages and Extrusion Resistance Efficiency

• Cotton Sheeting Reinforcement: Built with a 10.8 oz. cotton insert (5.0 oz. in 1/32" material) to provide exceptional extrusion resistance under bolt loading.
• Homogeneous Rubber Composition: Manufactured using 100% pure SBR rubber without fillers to preserve material integrity and product longevity.
• 80 Durometer Hardness Rating: Features high material density to withstand high mechanical forces on flat face flanges.
• Joint Sealing Integrity: Prevents gasket displacement under operational pressure inside our comprehensive Katalog Gasket collection.

Technical Specifications and Operating Boundaries

• Official Designation: Garlock Style 19 SBR Rubber Sheet (Garlock Part 51002-8330, 51002-8338, 51002-8346, and 51002-8361).
• Material Composition: Styrene-butadiene rubber (SBR) with a cotton cloth insert.
• Durometer Hardness: Shore A 80 (+/- 5).
• Color and Finish Options: Black branded with a satin/fabric finish.
• Operating Temperature Range: Minimum rating -23°C (-10°F) to maximum rating 93°C (200°F).
• Operating Pressure Range: Preferred working pressure 10 bar (150 psig) with maximum rating 17 bar (250 psig).
• Maximum P x T Factor: Rated at 600 bar x °C (20,000 psig x °F).
• Fabric Ply Construction: 1 ply for 1/32", 1/16", and 3/32" thicknesses; 2 plies for 1/8" thickness; 3 plies for 3/16" thickness; 4 plies for 1/4" thickness.
• Standard Thickness Selection: Thicknesses of 0.031 inch (0.8 mm), 0.063 inch (1.6 mm), 0.094 inch (2.4 mm), 0.125 inch (3.2 mm), 0.188 inch (4.8 mm), and 0.250 inch (6.4 mm) with a roll width of 40.0 inches (1016.0 mm).
• Compliance Certifications: Fully compliant with REACH and RoHS standards.
• Flange Assembly Guidance: Gasket fabrication requires precision cutting.

Physical ASTM Properties and Flange Engineering Design Factors

• ASTM D149 Dielectric Property: Evaluated at 31 volts/mil on a 1/8 inch test sample.
• ASTM F586 Design Factors: Features a design factor m value of 1.25 and factor y value of 2.8 N/mm² (400 psi).
• ASTM D2000 Line Callout Classification: Certified under line callout 2AA810A13 based on testing performed on rubber compound slabs without fabric inserts. Review our company profile on the Tentang Perusahaan page.

Industrial Applications and Fluid Weeping Guidelines

• Compatible Fluid Media: Engineered to handle water and wastewater fluid lines.
• Target Industrial Sectors: Broadly deployed across chemical processing, food and beverage, mining, pharmaceutical, water and wastewater, pulp and paper, oil and gas, nuclear, and primary metals industries.
• Operational Weeping Precaution: Cloth-inserted rubber may weep (leak through the fabric reinforcement) when deployed as a flat gasket. Evaluate fluid pressure conditions before material selection. Open our Kontak page to request price quotes and stock availability.
