Measuring Instrument Multi Gas Detection PGM-2400

Multi GAS detection instruments

Features:

• Patented SPE O2 sensor Oxygen ™ unique features: 1) Lead-free design that complies with RoHS directive; 2) Extended life compared to lead-type electrochemical oxygen sensors, resulting in a low cost of ownership; 3) Leak-free design, minimizing downtime
• Best EMI/RFI immunity technology for products in its class, eliminating radio interference
• Easy access to sensors, pump, filter and battery compartment without exposing potential damage to electronic components
• IP-65 water-and dust-resistant case
• Strong, protective, concussion-proof design

Advantages

• Plug-in sensors: oxygen, combustibles, hydrogen sulfide, sulfur dioxide or carbon monoxide
• Intuitive simple-to-operate two-button user interface with built-in pump
• The display can be flipped 180 degrees with the push of a button for easy viewing from a belt or hand
• Multiple-language support
• One-button with auto zero calibration capability
• Loud audible alarm 95dB
• Bright, visible flashing red alarm
• Vibration alarm
• Interchangeable drop-in Lithium-ion battery and alkaline battery packs

Applications:

• Oil & Gas
• HAZMAT
• Industrial Safety
• Environmental

Specifications
1. Size: Diffusion: 5 "w x 2.8" W x 1.5 "H (12.5 cm x 4.5 cm x 3.8 cm); Pump: 5 "w x 2.8" W x 2 "H (12.5 cm x 4.5 cm x 5.0 cm)
2. Diffusion: Weight: 9 oz (250 g); Pump: 12 oz (350g)
3. the Sensors • Catalytic bead for combustibles; • Oxygen: SPE O2 ™ (non-consumable Solid Polymer Electrolyte technology); • Toxic: electrochemical for H2S or CO
4. Interchangeable Lithium-ion Battery or alkaline battery packs
5. Operating Period: Diffusion: Up to 14 hours of continuous operation with Lithium-ion battery, up to
10 hours with alkaline battery (typical, without alarm); Pump: Up to 10 hours with Lithium-ion battery, up to 8 hours with alkaline battery
6. Graphic Display 4 lines, with the LED automatic back light in dim light or alarm condition
7. Two-button Keypad operation
8. Direct Readout • Instant reading from up to four sensors; • A u.s. percentage Oxygen by volume; • Combustible gases the u.s. percentage of the lower explosive limit (LEL), scalable using correction factors; • Toxic gases in parts per million; • High and low values for all gases; • Battery voltage and shutdown; • Date, time, elapsed time, temperature
9. Alarms • buzzer 95dB (at 30 cm, typical), vibration alarm, and flashing red LED; • High: 3 beeps, vibration and flashes per second; • Low: 2 beeps, vibration and flashes per second; • STEL and TWA: 1 beep, flash and vibration per second; • Alarms: latching with manual override or automatic reset; • Additional diagnostic alarm and display message for low battery; • Pump stall alarm (QRAE II Pump only)
10. the EMI/RFI Highly resistant to EMI/RFI. Compliant with EMC directive; 2004/108/EC additional + 60 volts/meter
11. IP Rating IP 65
12. Data logging Standard 12 days at one-minute intervals
13. A Two-point Calibration calibration for zero and span (manual, automatic or with the AutoRAE Lite)
14. Optional internal Sampling Pump, pump 300 cc/min
15. Hazardous Area Approval: • u.s. and Canada: C RUS CI, D1, Groups A, B, C, D, T4; • Europe: ATEX II 2 g EEx ia d IIc T4; • IECEX: Ex ia d II C T4
16. Temperature:-4 ° to 113 ° F (-20 ° to 50 ° C) for T4 temperature code
17. Humidity 0% to 95% relative humidity (non-condensing)
6. Attachments Stainless-steel alligator clip
7. Warranty Full two-year warranty, including all sensors
