Belimo LMQ24A‑SR – Very Fast Rotary Actuator

Belimo LMQ24A‑SR – Very Fast Rotary Actuator

The Belimo LMQ24A-SR is a high-speed non-spring return rotary actuator designed for HVAC applications that require fast and precise damper positioning. With a torque output of 4 Nm and a rotation time of just 2.5 seconds (for 90°), it is ideal for automated air handling and ventilation systems.

🔍 Key Specifications:

• Power Supply: 24 V AC/DC

• Control Signal: 2–10 V DC (modulating with position feedback)

• Torque: 4 Nm

• Rotation Angle: 95°

• Running Time: 2.5 seconds (for 90°)

• Protection Class: IP54 (dust and splash resistant)

• Connection Cable: 1 meter, 4 × 0.75 mm²

• Universal Clamp: Ø 8…26.7 mm shaft size
