Himel ELCB RCBO 1P+30mA 16 Ampere HDB3LE2C16 Current Breaker With Overcurrent

Key Specifications:

Product Type: RCBO (Combination of ELCB/RCCB and MCB in a single device)

Series / Model: Himel HDB3LE2C16

Number of Poles: 2P (1 Phase + Neutral)

Nominal Current ([In]): 16 Amperes (16A)

Trip Curve: C-Curve (magnetic tripping at 5–10x In)

Earth-leakage Sensitivity: 30 mA (protection against electric shock / human protection)

Operational Voltage ([Ue]): 230 V AC (50/60 Hz)

Electrical & Mechanical Specifications:

Trip Unit: Thermal-magnetic

Rated Impulse Withstand Voltage ([Uimp]): 4.0 kV

Mechanical Durability: 20,000 cycles

Electrical Durability: 10,000 cycles

Additional Functions: Circuit isolation, overload protection, short-circuit protection, and earth-leakage protection.

Environmental & Physical:

Operating Temperature: -35 °C to 70 °C

Mounting: 35 mm DIN rail

Degree of Protection: IP20 (Class II electrical shock protection)

Certification Standards: IEC 61009-1, CE certified

Weight: 185 g

Dimensions: 10 x 5 x 8
