Industrial Chemicals Insulating Varnish (K. 103 Ic)

Combination of resin, plasticizer, and solvent.

PHYSICAL PROPERTIES:

Form: Liquid

Color : Clear

Sg : ± 1.0

GENERAL DESCRIPTION:

Karmand – K. 103 IC is a material that is specifically formulated to isolate electrical equipment that is resistant to water vapor, heat, oil / grease and sunlight. This material is commonly used to insulate dynamo wire coils in electric motors. Resistant to high voltage. There are two types of products, namely Clear (clear) and Red (red). Each is used according to need.

USER GUIDE :

1. In Can Spray

Shake the can first, then spray it directly on the field to be isolated at a distance of 10-15 cm.

2. In liquid form

By brushing directly on the field to be isolated, if it is too thick it can be diluted with Karmand – Thinner IV. Dry touch ± 15 – 20 minutes, so that the coating can be thickened. Completely dry ± 2 – 3 hours.

PACKAGING :

Available in Can Spray 350 Gram and Pail 20 Liter.
