Easy-Laser BTA Series
Pulley & Belt Alignment

Easy-Laser® BTA is the perfect tool for sheave and pulley alignment. Mounted in a few seconds, the laser line projected onto the targets allows you to quickly ascertain and correct the misalignment. Approved for use in potentially explosive environments!

SPECS:
Sheave diameters B 60 mm [2.5”] and larger
Sheave thickness Not depending on sheave thickness
Beam angle 60°
Measurement distance 10 m [33 feet]
Battery type 1 x R6 (AA) 1.5 V
Battery operation >8 hours continuously
Laser class 2
Output power <1 mW
Laser wavelength 635–670 nm
Housing material ABS plastics/Hard anodized aluminium
Dimensions WxHxD: 145x86x30 mm [5.8”x3.4”x1.1”]
Weight 0.27 kg [8.6 oz]
Targets 2 pcs. magnet targets

Feature:
Because of its light weight it can be mounted on non
magnetic sheaves with double sided adhesive tape.

Calibration : The laserline generated by the tool is calibrated parallel to
the reference surface.
Accuracy:
Offset < 0.2 mm [0.008”], Parallelity < 0.05°
