Omron H5CN-YCN 48 V Timer Digital

Digital Timer, Omron 48 V H5CN-YCN Digital Timer, Omron H5CN-YCN 48 V Digital Timer Omron H5CN-YCN 48 V Digital Timer Rated supply voltage: 100 to 240 VAC (50/60 Hz) Operating voltage range: 85 to 110% of rated supply voltage Power consumption: Approx. 12 VA (at 240 VAC)/Approx. 2.5 W (at 240 VAC) Time range(Number of ranges): 1 Time range: 1 second to 99 minutes 59 seconds Input method: Contact: The input contact is open and short circuit No contact: Open collector transistor ON/OFF input Output mode: N: Power-on delay Control output(Contact output): SPDT resistive load : 3 A at 250 VAC (cosφ=1) Minimum applicable load: 10 mA at 5 VDC (failure rate: P Reference value) Reset system: Power reset/External reset Power reset: Minimum power unlock time: 0.5 seconds External reset and Gate: Minimum input signal width: 0.02 s Residual voltage: max 2 V. Timer mode: DOWN display timer (subtraction from time set to 0) Display method: 4 digit 7 segment LED Character height: 10mm Ambient temperature (Operating) : -10 to 55℃ (without icing) Ambient temperature (Storage): -25 to 65℃ (without icing) Ambient humidity (Operating): 35 to 85% Shock resistance: Destruction: 300 m/s 2 , 3 times each in 6 directions Damage: 100 m/s 2 , 3 times each in 6 directions Life expectancy: Power: 100,000 operations min. (3 A at 250 VAC resistive load) Mechanical: 10 million operations min. Installation method: Flush installation / Surface installation External connection method: 8-pin round socket Case color: Light gray (Munsell 5Y7/1) Applicable sockets: P2CF-08, P2CF-08-E, P3G-08 Accessories (sold separately): Soft Cover: Y92A-48D Hard Cover: Y92A-48B Flush mount adapter: Y92F-30 Weight: Approx. 110 grams The Most Complete and Cheapest Electrical Supplies and Equipment Center in Glodok and available online. With the need for supplies to companies, of course an online promotion is needed that can make it easier to find quality and competitive electrical goods and equipment online in terms of price. We provide various kinds of Mcb, Temperature, Contactor, SMC, Timer, and etc. DUNIAELECTRICAL: COMPETITIVE PRICES, QUALITY GOODS!!!
