Omron E3S-CL1 30 Vdc Photoelectric Switches

Photoelectric Switches , Photoelectric Switches E3S-CL1 Omron 30 Vdc, Omron Photoelectric Switches E3S-CL1 30 Vdc Photoelectric Switches E3S-CL1 Omron Square Shape Type Sensing method Distance setting Sensing distance White paper 200 x 200 mm, setting distance: 200 mm: 5 to 200 mm 200 x 200 mm White paper setting range: 40 to 200 mm Max differential distance 2%. distance setting Reflectivity characteristics (black-white error) max 2%. distance setting Red LED light source (660 nm) Power supply voltage 10 to 30 VDC ripple (p-p) including 10%. Max current consumption 35 mA. Open collector NPN/PNP output control (selectable) Max. 30 VDC. max 100 mA. Residual voltage: max 1.2 V (NPN output) Residual voltage: max 2 V (PNP output) Light-ON/Dark-ON operating mode is selectable Protective circuit output short circuit protection, power supply reverse polarity protection Response time Operate or reset: max 1 ms. Sensitivity settings Endless adjustment 6 rounds (with indicator) Ambient lighting Incandescent lamp: max 5,000 lx. Sunlight: max 10,000 lux. Ambient temperature range (Operating) -25 to 55℃ (no freezing or condensation) Ambient temperature range (Storage) -40 to 70℃ (no freezing or condensation) Ambient humidity range (Operating) 35 to 85 % (no condensation) Ambient humidity range (Strage) 35 to 95 % (no condensation) Insulation resistance 20 MΩ min. (Megger 500 VDC) Dielectric strength 1000 VAC 50/60 Hz 1 min Crushing vibration resistance: 10 to 55 Hz, double amplitude 1.5 mm each in X, Y and Z directions for 2 hours Shock resistance Crushing: 500 m/s2 3 times each in X, Y and Z directions IEC protection level: IP67 NEMA: 6P (indoor only) Connection method Pre-wired model (Cable length 2 m) Indicator Light Indicator (orange), Stability Indicator (green) Package Weight: Approx. 170 grams Accessories Instruction manual, Mounting bracket, Adjusting driver, M4 x 12 hex bolt (with spring washer, Flat washer) Casing Material: Diecast zinc Lens: Methacrylate resin Cover: Polyether sulfone Mounting Bracket: Stainless steel (SUS304) The Most Complete and Cheapest Electrical Supplies and Equipment Center in Glodok and available online. With the need for supplies to companies, of course an online promotion is needed that can make it easier to find quality and competitive electrical equipment and equipment online in terms of price. We provide various kinds of Mcb, Temperature, Contactor, SMC, Timer, etc. . DUNIAELECTRICAL: Competitive Prices, Quality Goods!!!
