AEMC Digital FlexProbe®Digital FlexProbe aemc

AEMC Digital FlexProbe® aemc

SPESIFIKASI

Digital FlexProbe® – AEMC Instruments

Jenis: Alat ukur arus AC digital dengan sensor fleksibel.

Model: 400D dan 4000D

Rentang arus: 20 mA–400 A AC (400D) dan 200 mA–4.000 A AC (4000D).

Rentang frekuensi: 10 Hz–3 kHz.

Resolusi: Hingga 1 mA, tergantung model.

Fitur: True RMS, tampilan digital, pengukuran langsung, dan fungsi HOLD.

Panjang sensor: 250–600 mm untuk 400D; 350–600 mm untuk 4000D.

Catu daya: 2 baterai AAA 1,5 V.

Daya tahan baterai: Sekitar 70 jam.

Kategori keselamatan: 600 V CAT IV.

Catatan: Spesifikasi dan ukuran sensor bergantung pada model yang digunakan.

TECHNICAL SPECIFICATIONS

Digital FlexProbe® – AEMC Instruments

Type: Digital AC current meter with a flexible sensor.

Models: 400D and 4000D.

Current range: 20 mA–400 A AC (400D) and 200 mA–4,000 A AC (4000D).

Frequency range: 10 Hz–3 kHz.

Resolution: Down to 1 mA, depending on the model.

Features: True RMS, digital display, direct reading, and HOLD function.

Sensor length: 250–600 mm for 400D; 350–600 mm for 4000D.

Power supply: Two 1.5 V AAA batteries.

Battery life: Approximately 70 hours.

Safety rating: 600 V CAT IV.

Note: Specifications and sensor dimensions depend on the selected model.
