SAUERMANN Si-CA 030 Combustion Gas Analyzer Model SICA 030 KIT 2BS Ref. No. 27498

SAUERMANN Si-CA 030 Combustion Gas Analyzer Model SICA 030 KIT 2BS Ref. No. 27498

Combustion analyzer Si-CA 030 Kit 2BS, with 2 electrochemical gas sensors (O2, CO) upgradeable to a 3rd sensor (NO), automatic pump cut-off protection for sensors, 300 mm sampling probe with 3 m hose and water trap with filter, magnetic support, protective rubber holster, power charger, USB cable, quick start guide and calibration certificate. Wireless communication for mobile application and remote printer (optional). Packaged in vinyl carrying case.

• Up to three gas sensors O2, CO and NO (for NOx)
• CO sensor measurement up to 8,000 ppm
• Auto pump cut-off for high CO levels
• Color display screen
• Lightweight, only 350 g (12 oz)
• Data management with automatic logging & report creation

MEASURE DETAILS

Units : inH2O, °F, °C, %, ppm, mbar

MEASURING RANGES

O2 : 0.00 % ... 25.00 %

CO : 0.00 ppm ... 8000.00 ppm

CO2 : 0.00 % ... 99.90 %

Flue temperature : -20.00 °C ... 1250.00 °C

Air temperature : -20.00 °C ... 120.00 °C

Differential temperature : 0.00 °C ... 1250.00 °C

Pressure/Draft : -200.00 mbar ... 200.00 mbar

Excess air : 0.00 % ... 999.00 %

Efficiency : 0.00 % ... 100.00 %

Efficiency (condensation) : 0.00 % ... 125.00 %

TECHNICAL DETAILS

Parameters : Gas analysis

Displays : Color graphical display

IP Protection : IP 42

Battery life : 8 hours

Standards : 2015/863 EU (RoHS 3), NF EN 50379-1, NF EN 50379-2, 2014/53/EU RED

Wireless connection : 1

Power supply : Rechargeable battery, Li-Ion 5100 mA/h 3.6 V

Usb : Yes

Sensors : CO, O2

Auto zero : Yes

Printer : Remote

Sensor protection : Sensor protection by pump stopping

Combustion condensate

Remote

Mobile application : Yes

INSTRUMENT DIMENSIONS

Length : 99 mm

Width : 49 mm

Height : 194 mm

Weight : 350 g

OPERATING TEMPERATURE

Min : -5.00 °C

Max : 45.00 °C

STORAGE TEMPERATURE

Min : -20.00 °C

Max : 50.00 °C
