IKA RC 2 GREEN control Temperature Control

General Laboratorium Supplies

IKA RC 2 GREEN control Temperature Control

Price

Request a quote

1 Unit Minimum Order

Price is not binding and may change at any time. Get the best price by clicking Request Quotation

Stock: 50
Country of Origin: Germany
Shipped From: Kemayoran, Jakarta Pusat
Category: General Laboratorium Supplies
Last Updated: 27 Oct 2026

Specifications of IKA RC 2 GREEN control Temperature Control

Explore a wide selection of General Laboratorium Supplies.

IKA RC 2 GREEN control Temperature Control

Description Product

Powerful, compact and energy-efficient recirculating chiller for cooling applications up to -30 °C. The on-demand and speed-controlled compressor, operated with natural refrigerant, achieves a cooling capacity of 800 W at minimum energy consumption.

The speed-controlled PEEK pump allows an indirect continuous adjustment of maximum pressure and flow rate. The device provides an external temperature control interface. A PT 100.30 temperature sensor is included in the scope of delivery. The wireless controller (WiCo) shows all relevant process parameters at a glance and enables comfortable and safe operation of the device.

highly efficient speed-controlled cooling unit with a cooling capacity of 800 W (@20 °C)
natural refrigerant R290
speed-controlled PEEK pump: (0.5 bar; 21 l/min)
digital level indicator
optical and acoustic warning functions
easy-to-clean stainless steel mesh filter
high quality insulated 4 l bath reservoir (minimum 1.5 l)

Interfaces:

RS 232 and USB for controlling and monitoring the devices via labworldsoft® and to update the software online
Calibratable internal temperature sensor (3 point)
LEMO socket for connecting an external PT 100 temperature sensor

Technical Data

Appliance type	Recirculating chiller
Cooling agent	R290
Cooling agent quantity	69 g
Cooling agent pressure max.	21 bar
Cooling capacity (@20°C)	800 W
Cooling capacity (@10°C)	700 W
Cooling capacity (@0°C)	500 W
Cooling capacity (@-10°C)	400 W
Cooling capacity (@-20°C)	200 W
Cooling capacity (@-30°C)	90 W
Working temperature	-30 - room temp. °C
Operating temperature min.	-30 °C
Operating temperature max. (with external heating)	70 °C
Temperature display	yes
Temperature stability DIN 12876 (@-10°C)	±0.15 K
Temperature control	PID
Working temperature sensor	PT 100
Working temperature display	TFT
Safety temperature display	TFT
Temperature stability DIN 12876	±0.15 K
Connection for ext. temperature sensor	PT 100
Display resolution	0.01 K
Set temperature resolution	0.1 K
Warning function optical	yes
Warning function acoustic	yes
Warning function excess temperature	yes
Warning function insufficient temperature	yes
Sub-level protection	yes
Filling volume	1.4 - 4.0 l
Pump type	Pressure- / suction pump
Pump capacity adjustable	yes
Pump pressure max. (0 liters discharge flow)	0.5 bar
Pressure pump (suction side) (0 liter flow)	0.25 bar
Flow rate max. (0 bar back pressure)	21 l/min
Pump connection	M16x1
Calibration option	yes
Technical data complies with the standard	DIN 12876
Noise level	61 dB(A)
Dimensions (W x H x D)	220 x 475 x 525 mm
Weight	26.5 kg
Permissible ambient temperature	5 - 32 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 21
RS 232 interface	yes
USB interface	Micro-USB
Voltage	230 V
Frequency	50/60 Hz
Power input	350 W
