Specifications of IKA EUROSTAR 40d plate stand Solution Overhead Stirrers

Explore a wide selection of General Laboratorium Supplies.

IKA EUROSTAR 40d plate stand Solution Overhead Stirrers

Description Product

EUROSTAR 40 digital is the right solution for simple mixing tasks up to 40 liters (H2O) and viscosities up to 30 000 mPas. Its maximum torque of 60 Ncm and linear adjustment to 40 Ncm at maximum speed guarantee reliable and powerful performance.

The innovative torque trend measurement shows the viscosity trend of the sample (+/- 6 Ncm accuracy). The torque trend is shown directly on the display and provides important feedback on the mixing process. The desired stirring speed 30-2000rpm is always guaranteed even with changes to the torque demand or viscosity of the material.

Connectivity and documentation
• USB and RS232 interfaces
• Compatible with labworldsoft® laboratory software for integration into digital workflows and documentation of processes

Features

• 23% smaller size than previous models

• Torque Trend Measurement

• Quick Sense Keyless Chuck

• Safety Stop Mode: When torque drops dramatically in case of vessel breakage

• Cleanroom ISO 7/8 Classification

• IP 54

Scope of delivery

EUROSTAR 40 digital
R 1826 Plate stand
R 182 Boss head clamp
R 1342
RH 3 Strap clamp

Technical Data

Stirring quantity max. per stirring position (H2O)	40 l
Motor rating input	118 W
Motor rating output	84 W
Motor principle	Brushless DC
Speed display	LCD
Speed range	0/30 - 2000 rpm
Viscosity max.	30000 mPas
Output max. at stirring shaft	84 W
Permissible ON time	100 %
Torque max. at stirring shaft	60 Ncm
Torque max. at stirring shaft at 30-200 rpm	60 Ncm
Torque max. at stirring shaft at 200-2000 rpm	60-40 Ncm
Speed adjustment	stepless
Setting accuracy speed	±1 rpm
Deviation of speed measurement n > 300rpm	±1 %
Deviation of speed measurement n < 300rpm	±3 rpm
Stirring element fastening	chuck
Chuck range diameter	0.5 - 10 mm
Hollow shaft, inner diameter	11 mm
Hollow shaft (push-through - when stopped)	yes
Fastening on stand	extension arm
Extension arm diameter	16 mm
Extension arm length	220 mm
Torque display	yes
Speed control	electronic
Nominal torque	0.4 Nm
Torque measurement	trend
Deviation of torque measurement I	±6 Ncm
Timer	yes
Timer display	LCD
Time setting range	1 - 6000 min
Housing material	alu-cast coating / thermoplastic polymer
Clean room qualified	yes
Noise without element	52 dB(A)
ISO Cleanroom Class (900rpm)	Class 7
ISO Cleanroom Class (1800rpm)	Class 8
Dimensions (W x H x D)	89 x 237 x 191 mm
Weight	3.8 kg
Permissible ambient temperature	5 - 40 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 54
RS 232 interface	yes
USB interface	USB-C
Voltage	100 - 240 V
Frequency	50/60 Hz
Power input	186 W
